Powerful motorized cornice Power 591
Window
Delimiter
Office
Conference hall
Sunscreen
For home
Hotel
Mounting pictures
Bathrooms
Ships
Bus, van
90 degree angle
Large bending angle
Arch
| Артикул: | 00000 |
| Accommodation | Внутренние
|
| Bend | 90 degree bend
Smooth radius bend |
| BY APPEARANCE | Technical
|
| BY TYPE of POWER SUPPLY | 220V
|
| Country of origin | Italy
|
| Product type | Curtain rods for draped curtains
|
| Profile height, (cm) | 3,5
|
| Profile width, (cm) | 3,9
|
| Brand | Mottura
|
| Mount type | Ceiling
Wall Inclined installation |
| Control type | Button
Remote controller Smart House |
| Type of curtain rod | Single
|
| Max fabric weight, kg | 160
|
heavy duty electric curtain rod for draped curtains
Electric curtain rod Power 591 is a heavy-duty motorized curtain rod for draped curtains, created by Mottura (Italy) for moving heavy draped curtains, as well as for covering large windows, as well as bay windows and openings with corners.
Motorized curtain rod Power 591 is an ultra-modern curtain rod system with low energy consumption. Compared to other electric curtain rods using a 230Vac motor, the Power 591 digital curtain rod motor guarantees energy savings of up to 70%.
The executive unit consists of a DC motor and control electronics, which controls the functioning of the curtain rod system. The assembly speed of the curtain fabric is 25 m/s. Power transmission is carried out using a timing belt made of polyurethane. Guaranteed maximum loads: length 24 m, curtain weight 160 kg. The motorized curtain rod Power 591 allows for side, central or asymmetrical opening.
The Power 591 electric curtain rod is equipped with a built-in radio receiver for using control - a radio remote control, but can also be controlled by a wired button or the Smart Home system
The Power 591 electric curtain rod is usually assembled using a single-channel profile but can also be assembled using a double-channel profile for large overlap curtains. To ensure a large overlap, it is also recommended that 2 Power 591 systems be installed in parallel and controlled from a wired remote control art. 5361 (or 5096/98).
Using the external button panel on the curtain rod motor, you can easily adjust the position of the limit switch and set the parameters of the built-in radio receiver.
Electric cornice Power 591 can have both ceiling and wall mounting. The cornice can bend at an angle of 90 degrees and along a smooth radius.
You can buy electric curtain rods in Kyiv in the VOGUE INTERIORS salon, where all Mottura (Italy) range samples are presented. You can also order curtain rods with delivery throughout Ukraine around the clock in our online store.
- white curtain rod profile made of aluminum
- a pair of end caps
- runners every 8-10 cm, art. 5028
- carriage, art. 5560
- ceiling mount, brackets every 80 cm, art. 5280
- digital motor, art. 5552
- polyethylene packaging
Attention: remote controls for the curtain rod and hooks for hanging curtains are not included in the curtain rod set and are supplied on request. Individual configuration is possible and provided on request.
- Profile of the curtain rod made of extruded aluminium alloy 6060 T6 UNI 8278
- curtain rod profile width: 39 mm, curtain rod profile height: 35 mm
- curtain rod profile groove: 6 mm
- curtain movement speed: 25 m/s
- 24 Vdc DC motor with power supply and wide-range switch for AC 90-250 Vac / DC 24V – 110 W – 5 Nm – 165 rpm
- Minimum bending radius of the curtain rod:
90° bend: 30 cm, smooth radius bend: 50 cm - Force transmission using a toothed belt made of polyurethane with a steel cord and a polyamide coating to reduce friction and wear
- curtain rod surface finish:
polyester coating in white color RAL 9016 - curtain rod runners made of impact-resistant thermoplastic with wheels on steel axles
- auto-lock motor insert and belt tension mechanism located in the bypass block
- curtain rod parts made of self-lubricating acetal plastic
